Samsung LUZON Multi Indoor Air Conditioning Unit AR09TXHZAWKNEU 2.5kW/9000BTU

*For Multi Split Systems Only, Please Call Us Before You Buy*

Samsung Luzon Multi Split Indoor Wall Mounted Air Conditioning Unit AR09TXHZAWKNEU A++ Inverter, 2.5kW/9000Btu

Key Features

Optimised Cooling and Heating

Cooling Capacity: Experience efficient cooling with a capacity of 8530 Btu/hr, ensuring comfort even in warm climates.

Heating Capacity: Stay warm during chilly weather with a heating capacity of 10919 Btu/hr, providing reliable warmth when needed.

Flexible Capacity Range

• Cooling (Min – Max): Enjoy adaptable cooling options ranging from 3071 to 11431 Btu/hr, catering to various room sizes and environmental conditions.

• Heating (Min – Max): Achieve customisable heating with a range of 3071 to 15355 Btu/hr, ensuring consistent warmth throughout your space.

Energy Efficiency

• SEER (Seasonal Energy Efficiency Ratio): Benefit from energy savings with a SEER rating of 6.70, ensuring efficient operation and reduced electricity costs.

• EER (Energy Efficiency Ratio) for Cooling: Experience efficient cooling with an EER of 3.57 W/W, providing optimal performance during cooling.

• COP (Coefficient of Performance) for Heating: Achieve efficient heating with a COP of 3.81 W/W, ensuring cost-effective heating solutions.

Quiet Operation

• Indoor Cooling: Enjoy quiet indoor cooling with a sound level of 54 dBA, creating a peaceful indoor environment.

• Outdoor Cooling: Experience outdoor cooling without disturbance, with a sound level of 63 dBA.

Advanced Sound Control

• Indoor (High/Low): Adjust sound levels indoors with options ranging from 37 dBA to 19 dBA in high and low modes respectively.

• Outdoor (High): Stay undisturbed outdoors with a sound level of 46 dBA in high mode.

Efficient Electrical Data

• Power Source: Operate efficiently with a power source of 1/220-240/50 Ø/V/Hz, ensuring consistent performance.

• Power Consumption: Save energy with power consumption of 700 W for cooling and 840 W for heating.

• Operating Current: Maintain optimal operation with operating currents of 3.6 A for cooling and 4.0 A for heating.

Streamlined Design and Installation

• Gross Dimensions (Indoor/Outdoor): Enjoy sleek design with dimensions of 880x290x375 mm for indoor units and 778x550x331 mm for outdoor units.

• Net Dimensions (Indoor/Outdoor): Benefit from space-saving design with net dimensions of 820x299x215 mm for indoor units and 660x475x242 mm for outdoor units.

• Weight: Ensure easy handling with indoor units weighing 11.1 kg (gross) and 9.1 kg (net), and outdoor units weighing 24.3 kg (gross) and 22.6 kg (net).

Flexible Installation Options

• Piping Length/Height: Benefit from flexible installation options with a maximum piping length of 15 m and maximum height of 8 m, ensuring suitability for various spaces.

• SVC Valve: Ensure efficient refrigerant flow with liquid and gas SVC valves of 6.35 mm and 9.52 mm respectively.

Enhanced Features for Comfort

• Moisture Removal: Maintain comfortable indoor humidity levels with a moisture removal rate of 1.0 l/hr.

• Air Circulation: Enjoy improved air circulation with a rate of 10.5 ㎥/min, ensuring even distribution of cooled or heated air.

Advanced Air Purification

• Easy Filter Plus: Improve indoor air quality with the Easy Filter Plus, capturing dust, allergens, and bacteria for cleaner air.

• Auto Clean Function: Maintain fresh indoor air with the auto-clean function, preventing the growth of fungus and bacteria inside the unit.

Convenience Features

• Convenience Features: Benefit from convenient features such as filter cleaning indicator, indoor temperature display, display on/off, beep on/off, 24-hour timer, auto changeover, and auto restart.

Operating Modes

• Operating Modes: Choose from various operating modes including auto, fast cool/heat, good sleep, eco mode, dehumidification, fan mode, and quiet mode.

Reliable Build and Operation

• Outdoor Unit Features: Benefit from efficient BLDC compressors and anti-corrosion fins, ensuring durability and longevity of the outdoor unit.

This comprehensive specification ensures optimal cooling and heating performance, energy efficiency, convenience, and comfort for your indoor environment.

R32 is the next generation refrigerant that boasts nearly 70% lower Global warming potential rate that R410A. Due to its superior qualities R32 offers amazing energy efficiency benefits. It has a potential refrigerating effect 1.5 times that of R410A meaning it needs less energy to achieve the desired temperature and requires less refrigerant volume to operate.

Warranty: This air conditioning system comes with 7 years manufacturer’s only parts warranty.

Please Note; this air conditioning system has to be installed by an F-GAS Certified Installer in accordance with F-GAS regulations, and to validate and maintain the above manufacturer’s parts only warranty. We offer installation in most parts of UK, please contact us for installation price. Alternatively you may hire an F-GAS Certified Installer to install this system and provide us the evidence of it once installation is completed. This is a requirement of the Article 11 (5) EC/517/214 on Fluorinated Greenhouse Gases and the Fluorinated Greenhouse Gases Regulations 2015.

Click on ‘Download File’ below for Product Brochure.
